| Detector typeAuto | Types of detectionsInfrared; Magnetic; Optical density control; Geometric banknote control; Special element "I"; Double check; UV detection of ultraviolet marks | Verification speed0.5 s/banknote |
| Types of currenciesRUB | Summation modeNo | Determining the denomination of a banknoteNo |
| Banknote orientation optionsAny side | Saving data on verified banknotesYes | Banknote issuance modeDirect and reverse |
MERTECH D-20A Promatic GREENRED is an automatic banknote detector that operates on a battery. The model features PSD detection and Anti-Stox (IAS) systems. After verification, a red or green signal lights up on the display.
Advantages of this Model
The small device does not take up much space on the desk. There is a place for installation in the cash zone of a store, pharmacy, cafe, beauty salon, gas station, and other businesses. Banknote analysis is performed through 8 detections:
- Infrared;
- Ultraviolet;
- Magnetic;
- Optical density control;
- Geometric control of the banknote;
- Special element "I";
- Spectral characteristics;
- Double-check
Two LED displays are installed on the front panel: green and red. If the banknote is recognized as genuine, the green display activates. If the banknote is suspicious, the green display activates along with an audible signal.
The accuracy of automatic verification is high. This is confirmed by testing results from the Ministry of Internal Affairs's forensic center. The device's design is very simple: even staff with low qualifications can check money for authenticity.
Technical Specifications
The device is made of polycarbonate and plastic. The reliable casing protects the electronics from falls from table height. The mechanism accepts money inserted from any side. During verification, money is fed in both forward and reverse.
Verification of banknotes is performed one by one. Analyzing a banknote takes 0.5 seconds. The detector has memory to store results. The device only works with rubles. The firmware can be updated after new banknotes are released.
The detector operates from a high-capacity battery. One charge lasts for 9 hours of continuous operation with banknotes. A power supply adapter is used to charge the battery. The charged device can be taken for field transactions.
How to Place an Order
MERTECH offers to purchase detectors at manufacturer prices. Delivery of orders from the online store is carried out throughout Kazakhstan. Leave a request on the website or by phone, and we will prepare a beneficial offer for you.
| Detector type | Auto |
|---|---|
| Types of detections | Infrared; Magnetic; Optical density control; Geometric banknote control; Special element "I"; Double check; UV detection of ultraviolet marks |
| Verification speed | 0.5 s/banknote |
| Types of currencies | RUB |
|---|---|
| Summation mode | No |
| Determining the denomination of a banknote | No |
| Banknote orientation options | Any side |
| Saving data on verified banknotes | Yes |
| Banknote issuance mode | Direct and reverse |
| Possibility of independent software updates | Yes |
| Sound and visual indication | Yes |
| Guarantee | 2 years |
|---|---|
| Battery | Li-On |
| Storage temperature | -20°С ~ +65°С |
| Nutrition | Power adapter DC12V/1.0A |
| Permissible humidity | 80% |
| Operating temperature | 0-40°С |
| Detection indication | Yes |
|---|---|
| Indication of a genuine banknote | Green |
| Indication of a suspicious banknote | Red |
| Number of indication digits | 12 (6+6) |
| Interfaces | USB |
|---|
| Battery capacity | 10.8V/600mAh |
|---|
| Color | Black |
|---|---|
| Overall dimensions (WxDxH), mm | 135*165*85 |
| Body material | ABC + PC (plastic + polycarbonate) |
| Weight | 650 |
| Detector | Eat |
|---|---|
| User manual | Eat |
| Power adapter | Eat |
-
